Display parameters
| Parameters | Data | Instructions |
| Display size | 21.5 inch | 16:9 |
| Resolution | 1920*1080 | |
| Colors | 16.7M | - |
| Active Area dimenstion(A.A) |
476.64(H)*268.11(W) mm
|
- |
| Backlight brightness | 250 nit | The brightness can be adjust by software |
| Backlight lifetime(Hrs) | 50000Hrs | LED backlight |
| Viewing direction(CR>10) | wide view angle | |
| Touch type | Capacitive touch panel | Support single or 10 point touch |
| Working life |
Single point can affordable
≥50 million times
|
|
| Response time | 8ms | |
| Case size |
510.4*269.8*25.4 mm
|
Hareware parameters
| CPU |
RK3568 4 cores 64-bit Cortex-A55, maximum main frequency 2.0Ghz
|
|
Memory
|
2G |
|
Storage
|
EMMC FLASH 16G (the maximum can be extended to 32G) |
|
GPU
|
ARM G52 2EE support OpenGL ES 1.1/2.0/3.2,OpenCL 2.0,Vulkan 1.1
|
| WIFI |
2.4GHz
|
| Bluetooth |
BT 4.0
|
| Operation system |
Android 11
|
| Others | Support RTC real-time clock, ,timing switch |
| Language |
Chinese, English, French, German, Italian, Japanese, Korean, Russian, Spanish,
Polish, Czech and many other languages.
|
|
item
|
value
|
|
Type
|
TFT
|
|
Supplier Type
|
China factory directly supply
|
|
Place of Origin
|
China
|
|
Brand Name
|
Huayuan
|
