10.1inch HDMI lcd module hot sell
10.1 inch standard display with HDMI input
Can be used as a Raspberry Pi display with touch control
function (touch driver required)
Can be used as standard HDMI output devices such as computer
monitors, TV boxes, and PSPs
Product characteristics
1. Resolution: 1024×600 / 1280×800 / 1920×1200 (Optional)
2.Compatible with most versions of Raspberry Pi and can
plug in directly
3.Support Raspberry Pi OS/Ubuntu/Windows system
4.Do not use touch function, does not occupy any I/O
resources (use touch function, occupy I/O)
5.Support HDMI audio output( Optional )
6.Support multi-Chinese OSD menu (can be used for power
control, adjust brightness/contrast, etc.)
Installation method
1. It is recommended to use the specified voltage range to drive the LCD panel, try
to adjust the working voltage to achieve the best contrast, the color and contrast
of the LCD panel will be different at different temperatures;
2.In the lower operating temperature range, the response time of liquid crystals
is greatly delayed. But this does not mean that the liquid crystal will fail, so
that it returns to the specified temperature range and it will return to its normal
state;
3.If the LCD module is subjected to hard object pressure during operation, the LCD
module will become abnormal;
4.The use of LCD in the environment under specific conditions may lead to the damage
and shortening of the life of the liquid crystal;
Warranty period
1.According to the inspection and acceptance criteria (or agreed requirements), if
the product is found to be defective, our company provides 12 months of product
maintenance guarantee service from the production date of the product inkjet
printing;
2.Any defective product must be returned within 60 days of receipt of the goods,
based on the delivery document;
3.If the following problems are caused by improper protection precautions, the
warranty will not be provided:
LCD cracked/cracked
The PCB socket is damaged or modified
Damaged PCB conductor PCB
The circuit is artificially polished, engraved or painted with paint
FPC has fractures
4.The defective module must be clearly identified as a problem, any connected objects
installed must be completely separated and removed without damaging the PCB socket,
circuit and terminal, and the LCD display must be packaged and transported in a
special box;
