LCD Application for Radxa Dragon Q6A (QCS6490)

Display Interface Capability
• 1 × 4‑lane MIPI‑DSI: support MIPI TFT LCD up to FHD+ resolution

• 1 × HDMI2.0: output up to 4K@30Hz for external display module

• Dual‑display simultaneous output (MIPI panel + HDMI display)

• Native no LVDS / RGB interface, converter board required for LVDS/RGB panels

Compatible LCD Types

• MIPI‑DSI TFT module (with CTP capacitive touch or RTP resistive touch), air‑bonding / optical full lamination, industrial wide‑temperature panel

• HDMI‑integrated TFT display module, commercial signage panel, magic mirror mirror‑type LCD

Application Fields

1. Dual‑screen POS Cash Register
Dual independent display: MIPI for customer secondary touch screen, HDMI for operator main screen, with face recognition AI function.

2. Self‑service Kiosk Terminal
Self‑order kiosk, vending machine, inquiry terminal; support industrial wide‑temperature touch TFT.

3. Digital Signage & Advertising Player
HDMI drive large‑size commercial LCD / magic mirror display, 7×24hrs content playback via Wi‑Fi 6.

4. Industrial HMI Control Panel
7‑10.1 inch MIPI industrial TFT touch screen for automation equipment.

5. Smart Home Magic Mirror
Work with mirror‑type magic mirror LCD for bathroom smart mirror, fitness mirror.

6. Medical & Embedded Tablet Terminal

MIPI touch TFT running Android / Yocto Linux for edge‑AI embedded devices.
