Full Specifications for LCD / Touch Modules of Medical Multi-Parameter Monitors

Full Specifications for LCD / Touch Modules of Medical Multi-Parameter Monitors

Distinction: Bedside Monitor Main Display vs Nursing Station Central Large Display

Core Reminder: Patient monitors are Class II medical devices, NOT ordinary industrial displays. The LCD/touch module is a critical component and must be included in the technical documentation for device registration. Changing the screen supplier constitutes a registration variation, which involves a long lead time. Most customers develop their own ARM mainboards and purchase open-frame touch modules instead of finished panel PCs. All-in-one panel PCs are only occasionally adopted for central monitoring workstations.

1. Size & Resolution

Bedside Monitor Main Unit (Main Focus, High-Volume Segment)

• 7” (portable / transport monitors, ambulances)

• 8”, 10.1”, 12.1” (Bestsellers! 1024×768 XGA, 4:3 aspect ratio is the industry classic)

• 4:3 is preferred for clean layout of ECG waveforms, ST-segment data and multi-parameter readings; 16:9 is gradually adopted in new-generation models

Central Monitoring Station (Large-Screen Segment: 15.6 / 18.5 / 21.5” FHD)

Used by nursing staff at back-end stations to view multiple patients’ waveforms, alarms and trend reports simultaneously. Sizes above 15.6” apply only to this scenario.

2. Optical Requirements (Accurate ECG Waveform Rendering is Critical)

1. Brightness

• General wards: 350–500 cd/m²

• ICU, operating rooms, windowsides with strong ambient light: 600–800 cd/m²

• Ambulance transport (outdoor strong sunlight): ≥1000 cd/m², sunlight readable

2. Panel: Mandatory IPS wide viewing angle (178°/178°)
Doctors, nurses and patients view waveforms from various angles. Color shift or blurry ECG traces are unacceptable; TN panels are generally rejected.

3. Contrast Ratio: ≥800:1; ≥1000:1 recommended for clear differentiation between waveforms and background.

4. Surface Treatment: AG anti-glare + AF anti-fingerprint / anti-corrosion coating. Many customers require OCA optical bonding to reduce reflection, prevent condensation and improve vibration resistance.

5. Color Depth: 8-bit with stable color performance. Non-diagnostic monitoring screens do NOT require DICOM (DICOM is mandatory only for medical imaging diagnostic displays).

6. Backlight MTBF: ≥50,000 hours for 24/7 continuous operation. No flicker allowed. PWM dimming may interfere with ECG acquisition; DC dimming backlight is strongly preferred.

3. Operating Temperature & Humidity

• Standard range: 0℃ ~ +60℃ (indoor ward environment)

• Ambulance / pre-hospital emergency version: -20℃ ~ +70℃ wide temperature

• Humidity: 5～95% RH, non-condensing. Optical bonding helps mitigate condensation.
