RK3588 Applications in Industrial All-in-One PC

• RK3588: Flagship all-rounder, four displays + 8K, 6TOPS, 8nm, superior performance and interfaces

RK3588 Applications in Industrial All-in-One PCs

Core Advantages

• High Performance & Low Latency: 8nm octa-core processor (4×A76 + 4×A55) for stable heavy-duty computing and real-time control.

• Powerful AI Computing: 6TOPS NPU supports local AI detection, visual recognition and intelligent analysis without cloud dependency.

• Rich Industrial Interfaces: Dual Gigabit Ethernet, RS232/485, CAN, PCIe 3.0, USB3.1 for full industrial protocol compatibility.

• Multi-Screen & 8K Video: Quad-display output, 8K@60fps decoding, ideal for production dashboards and monitoring.

• Industrial-Grade Reliability: Wide temperature range (-40℃~85℃), fanless design, EMC protection for harsh environments.

• Flexible OS Support: Android, Ubuntu, Debian, RT-Linux for diversified industrial needs.

Typical Applications

1. Smart Manufacturing
MES terminals, production HMI, digital SOP displays, CNC and robot control panels.

2. AI Industrial Vision
On-site defect inspection, size measurement, OCR recognition, multi-camera real-time processing.

3. Edge Computing & IoT Gateway
Industrial data collection, protocol conversion, 4G/5G/Wi-Fi6 networking, offline autonomous operation.

4. Industrial Monitoring & Security
8K video surveillance, intelligent NVR, power/energy monitoring terminals.

5. Special Industrial Scenarios
Explosion-proof panels, AGV/vehicle-mounted control terminals, mobile workstations.

Selection Guide

• Recommended version: RK3588J (industrial grade)

• Memory: 8GB–32GB LPDDR4x/LPDDR5

• Storage: eMMC + NVMe SSD

• Heat dissipation: Fanless / passive cooling

• Interfaces: Dual Gigabit LAN + multi-serial ports + CAN

Comparison with RK3566/RK3568

• RK3566: Entry-level, low power, basic HMI applications

• RK3568: Mid-range, triple-display, general industrial control

• RK3588: Flagship, AI-powered, multi-screen, 8K, high-performance edge computing
