17"/19"/21.5"/24"/32"etc. LCD Monitors for X Ray Scanner

Application Directions and LCD Technical Requirements
1. Application Directions

Two mainstream scenarios: Medical X-ray Diagnosis and Security Inspection X-ray Scanner

1.1 Medical X-Ray Imaging Industry

• Diagnostic X-ray Machine / DR / CR
Used to display digital X-ray images for doctor diagnosis in orthopedics, chest examination, dentistry and other departments.

• CT Scanner (Computed Tomography)
Presents tomographic reconstruction images, multi-planar views and 3D reconstructed images.

• Mammography X-ray Equipment
Displays tiny tissue structures and micro calcifications for breast examination with ultra-high image accuracy requirements.

• Fluoroscopy X-ray / C-arm System
Real-time dynamic image display for surgical guidance and interventional therapy.

• Dental X-ray Imaging System
For dental films, periapical films and panoramic dental imaging display.

Core Functions: Restore high-precision grayscale images, identify subtle lesions, provide diagnostic reference, support long-term stable medical image viewing.

1.2 Security & Industrial X-Ray Scanner Industry

• Baggage X-ray Scanner for Airport, Railway and Subway
Show internal structure of luggage, identify dangerous goods and contraband.

• Cargo & Container X-ray Scanner for Customs and Border Inspection
Large-scale scanning and image display for trucks and containers.

• Security X-ray Equipment for Prison, Court and Government Buildings
Safety inspection display for personnel and parcels.

• Industrial NDT X-ray Testing Equipment
Detect internal defects of castings, welds, electronic components and pipelines.

• Parcel X-ray Scanner for Logistics and Express Delivery Industry
Real-time imaging display for express parcel safety inspection.

Core Functions: Distinguish object outline and density, identify contraband clearly, support long-time stable operation, and adapt to public complex environments.
2. LCD Technical Requirements

2.1 Product Positioning

Medical X-ray

• Adopt professional medical imaging monitors, divided into Diagnostic Grade and Review Grade.

• Must comply with DICOM GSDF grayscale calibration standard.

• Mainly vertical screen / square screen, applied in professional reading workstations.

Security X-ray

• Adopt industrial rugged LCD monitors, not medical grade certified.

• Mainly horizontal screen, embedded or desktop installation for operation console.

• Focus on durability, anti-interference, sunlight visibility and vandal-proof performance.

2.2 Size & Aspect Ratio

Medical X-Ray

• Diagnostic Grade: 21.3", 24.1", 27", 30" (4:3 / 5:4 mainstream)

• High-precision Mammography: 21.3", 26"

• Portable / Dental: 10.4", 12.1", 15", 19"

Security X-Ray

• Regular Baggage Scanner: 19", 21.5", 22", 23.8" (16:9 mainstream)

• Compact Embedded Type: 10.1", 12.1", 15", 17"

• Large Cargo Inspection & Monitoring Room: 27", 32"

2.3 Resolution & Image Performance

Medical X-Ray

• Professional resolution: 2MP, 3MP, 5MP, 8MP, 12MP

• High-end mammography: 5MP and above

• Grayscale Depth: 10~16 bit grayscale, rich layering for subtle density difference identification

• Strict requirements: No dead pixels, uniform brightness, stable grayscale, low screen flicker, low noise

Security X-Ray

• Mainstream Resolution: 1920×1080 FHD, 2560×1440 2K

• High color depth, support pseudo-color display for organic / inorganic material classification

• Smooth dynamic picture, no ghosting, clear image after zooming

2.4 Brightness, Contrast & Grayscale

Medical X-Ray

• Brightness: 300~1000 cd/m², keep stable after DICOM calibration

• Contrast Ratio: 1000:1 ~ 2000:1 and above

• Support long-term DICOM calibration and regular quality control

• Low reflection surface to avoid light interference during film reading

Security X-Ray

• Brightness: 400~800+ cd/m², visible under strong indoor light

• Contrast Ratio: 800:1 ~ 1200:1, clear object boundary display

• Surface treatment: Anti-glare(AG), Anti-reflection(AR), scratch-resistant tempered glass

2.5 Viewing Angle & Panel

• Both medical and security applications require IPS 178°/178° full viewing angle

• Ensure no color shift and image distortion when viewed from multiple angles

2.6 Touch Function (Optional)

• Medical version: PCAP capacitive touch, antibacterial coating, resistant to disinfectant wiping, water-proof

• Security version: Capacitive / Resistive touch available, anti-fouling, anti-static, support glove touching

2.7 Environmental Adaptability & Certification

Medical X-Ray

• Operating Temperature: 0℃ ~ +50℃

• Backlight Lifespan: ≥ 50,000 hours

• Low EMC electromagnetic interference, no impact on surrounding medical equipment

• certifications: IEC 60601, CE Medical, FDA, ISO 13485

Security X-Ray

• Wide Temperature Grade: -10℃ ~ +60℃

• Anti-vibration, shock-proof, dust-proof and strong electromagnetic anti-interference

• Front panel optional IP65 dustproof and waterproof

• Certifications: CE, FCC, RoHS, UKCA, KC

2.8 Interface & System Compatibility

• Medical: DP, HDMI, DVI, SDI; compatible with Windows / Linux medical workstation system

• Security: HDMI, VGA, DVI, LVDS, eDP; match industrial computer and embedded mainboard

2.9 Color & Grayscale Performance Core

• Medical X-ray: Professional monochrome grayscale screen, strictly DICOM calibrated, restore real X-ray density layers

• Security X-ray: Color high-performance screen, display pseudo-color to distinguish goods density and dangerous goods
3. English Selling Points

For Medical X-Ray Scanner

• Professional medical-grade LCD monitor for DR, CT, X-ray and mammography imaging

• DICOM Part14 GSDF factory calibrated for accurate grayscale reproduction

• High resolution and high grayscale depth for subtle lesion detail detection

• IPS full viewing angle, consistent image performance in all viewing directions

• Long lifespan backlight, low noise, stable for clinical diagnostic use

• Complete medical certifications for hospital and medical institution projects

For Security X-Ray Scanner

• Industrial rugged LCD monitor for baggage, parcel and cargo X-ray inspection equipment

• High brightness sunlight readable display, clear image under bright ambient light

• High contrast image output for easy identification of contraband and hidden items

• Wide temperature design, anti-vibration and EMC protection for 24/7 continuous operation

• Rugged tempered glass surface, scratch proof and vandal resistant

• Full international certifications for global security and industrial market sales
