10"/15.6"/19"/24"/27"etc. Touch Screen for Stair master

Applications and LCD Performance Requirements

1. Application Scenarios

1.1 Applicable Product Types

• Commercial Grade Stair Master / Stair Climber / StepMill
Widely used in commercial gyms, hotels, clubs, corporate fitness rooms and public fitness centers.
Features: high-frequency daily use, long standby hours, shared by multiple users, high durability requirement.

• Home Grade Stair Master
Suitable for family personal exercise and small private training studios.
Features: stable performance, easy cleaning, cost-effective and beautiful appearance.

1.2 Core Functions of Touch Screen & LCD Display

• Display real-time workout data: time, step frequency, speed, calorie consumption, heart rate, floor count, distance and resistance level.

• Support workout program selection: manual mode, fat burning mode, interval training, HIIT, heart rate control, custom programs and mountain climbing simulation.

• User management: user account login, data memory function and ranking display.

• System settings: brightness adjustment, volume control, multi-language selection, Wi-Fi / Bluetooth connection, device maintenance and firmware upgrade.

• Entertainment functions: video playback, music, screen casting, online courses and virtual scene training.

• Safety reminders: emergency stop prompt, fault alarm and operation guidance.

2. LCD & Touch Screen Technical Requirements

2.1 Size and Aspect Ratio

• Commercial Models Popular Sizes:
10.1", 13.3", 15.6", 18.5", 21.5"
Aspect ratio: mainly 16:9; vertical screen and square screen optional.

• Home / Compact Models Popular Sizes:
7", 8", 10.1"

• Structural design: narrow bezel, embedded installation, slim body, stable structure to match fitness equipment housing.

2.2 Panel Performance

• Adopt IPS panel as priority, 178° wide viewing angle, no color shift when viewing from side or overlooking.

• True-color TFT-LCD, rich color display, clear fonts, icons and interactive interface.

2.3 Resolution

• Entry Level: 7"–10.1" — 800×480, 1024×600

• Commercial Mainstream: 10.1"–15.6" — 1280×800, 1920×1080 FHD

• High-end Premium: 15.6" and above — 1920×1080, 2K resolution for video and virtual scenes

2.4 Brightness, Contrast and Surface Treatment

• Brightness: 400–600 cd/m² standard for commercial use;
500–800 cd/m² high brightness optional for strong light gym environment.

• Contrast Ratio: ≥ 800:1 ~ 1000:1, clear text without grayish screen.

• Surface glass treatment:

◦ AG anti-glare coating, avoid reflection under indoor lamp light

◦ 7H hardness anti-scratch tempered glass

◦ AF anti-fingerprint coating, easy to clean sweat and dirt

2.5 Touch Solution

• Mainstream: PCAP Projected Capacitive Touch
2–10 points multi-touch, fast response, no touch drift.
Support sweaty hands, wet hands and light gloves operation.
Anti-static, anti-electromagnetic interference, adapt to complex gym electrical environment.

• Economical Option: Resistive touch screen, low cost, pressure sensing operation.

2.6 Environmental Adaptability & Reliability

• Operating Temperature: 0℃ ~ +50℃, suitable for indoor long-term use.

• Backlight Lifespan: ≥ 50,000 hours.

• Anti-vibration and shockproof design, adapt to mechanical vibration during equipment operation.

• Excellent EMC / EMI anti-interference performance, stable display and touch without signal disorder.

• Low power consumption and low heat generation.

• Optional front panel IP54 / IP65 dustproof, waterproof and sweat-proof protection.

2.7 Interface & System Compatibility

• Display Interfaces: LVDS, eDP, MIPI, HDMI, RGB

• Touch Interfaces: USB, UART / RS232, plug and play with stable drivers

• Compatible Systems: Android, Linux, Windows and dedicated fitness equipment operating systems

• Easy integration with original main control boards of stair climbers

• Professional industrial touch display customized for Stair Master / Stair Climber / StepMill

• IPS full viewing angle, anti-glare and anti-scratch tempered glass, clear vision under gym bright lights

• High-sensitivity capacitive touch, sweat-proof and wet-hand friendly for long-time public fitness scenarios

• High brightness option available, stable for 24/7 commercial gym operation

• Anti-vibration and anti-interference design, long service life and low maintenance cost

• Complete certifications, suitable for global commercial fitness and home fitness markets
